Sale!

Mondraker Play 24 Kids E-Bike 2023

2,199.00

Mondraker Play 24

  • New 24 Stealth Alloy frame
  • RockShox Judy Silver TK 100mm fork
  • Mahle e-Bikemotion Hub Motor
  • 250Wh integrated battery



In stock

SKU: 318130-001 Categories: ,

Description

Features – PLAY 24 – The first serious E-Bike for kids

The Mondraker Play 24 is one of the lightest children’s e-bikes on the market. In addition, the longer wheelbase makes it much more stable than other bicycles; whether on forest roads, trails or asphalt.
Price-performance is also very good. Just for comparison: a Woom Up 6 costs, for example, 2,990 euros.

Internally placed cables are of course a standard feature of the Play, as are the typical Mondraker technologies such as “Stealth Alloy” and the famous Mondraker “Forward Geometry”. This ensures a longer reach, which is created by the extended top tube and allows a longer wheelbase, which leads to more control and sovereignty. The rider moves further away from the front wheel, so the stem is very short.

The geometry and specifications of the Play 24 and the Play 26 have been adapted to the needs of young riders and provide a lot of off-road fun.

The 11-speed SRAM NX drivetrain together with the Mahle E-bike motion engine ensures that even steep ramps can be conquered. SRAM Level disc brakes with 160 mm diameter front and rear provide perfect deceleration. The wide Kenda Booster tires offer optimal grip on the road and on the trail. Hop on, ride on, have fun – because that’s guaranteed with this kids’ e-mountain bike!

The Stealth Alloy frame of the Mondraker Play 24 doesn’t just look instantly ‘Mondraker’, it delivers our legendary super stable, lightweight performance with a wide fit range for growing groms. Mahle e-Bikemotion X35 hub motor and integrated 250Wh battery shrink climbs and distances so your kids can become your new best bike buddies and develop their MTB skills and confidence. Forward Geometry handling, RockShox Judy forks with 100mm of kids tuned suspension, fully hydraulic disc brakes, SRAM NX 11-speed transmission and Mondraker Kids components complete a truly trail-ready spec.

Technical Details

    • frame

      Frame

      Play 24 6061 Alloy Stealth Evo, hydroformed tubing, integrated internal non-removable battery, Tapered head tube, HHG internal cable routing, BSA bottom bracket, QR 9mm rear axle, 1x drivetrain compatible

      sizes

      Sizes

      One size: 320mm

    • fork

      Fork

      RockShox Judy Silver TK 26, 100mm, TurnKey, Solo Air, tapered steerer tube, 9x100mm axle, 30mm steel stanchions, 40mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload

      headset

      Headset

      ONOFF Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41×30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

    • stem

      Stem

      ONOFF Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore

      handlebar

      Handlebar

      MDK XC 1.0, 6061 alloy, rise: 25mm, width: 580mm, 9º backsweep, 5º upsweep, 31.8mm barbore

    • grips

      Grips

      ONOFF Twin, 1lock-on, 135mm

      seatpost

      Seatpost

      MDK XC 0-R, 6061 T6 Alloy, diameter 31.6mm, length 300mm

    • saddle

      Saddle

      SDG Fly JR

      front brake

      Front brake

      SRAM Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad

    • rear brake

      Rear brake

      SRAM Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad

      brake lever

      Brake lever

      SRAM Level, tooled reach adjust, lever pivot bushings

    • rims

      Rims

      MDK-XP1 24 TLR, 25mm internal width, tubeless ready, 32 spokes

      spokes

      Spokes

      CN round stainless steel

    • front hub

      Front hub

      Formula DC20LW, 9x100mm, cup & cone ball bearings, IS 6 bolts

      rear hub

      Rear hub

      Mahle-Ebikemotion X-35

    • front tire

      Front tire

      Kenda Booster 24×2.4 single compound 30TPI, wire bead

      rear tire

      Rear tire

      Kenda Booster 24×2.4 single compound 30TPI, wire bead

    • crankset

      Crankset

      Prowheel, Direct mount chain ring, 127mm

      rings

      Rings

      28T, steel

    • bottom bracket

      Bottom bracket

      Prowheel BSA, 73mm

      chain

      Chain

      SRAM PC1110 11s, Powerlock

    • rear derrailleur

      Rear derrailleur

      SRAM NX, 11s, long cage, X-actuation 1:1

      shift levers

      Shift levers

      SRAM trigger NX 11s, X-actuation 1:1

    • casette

      Casette

      SRAM PG 1030 11-42T, 11s

      derailleur hanger

      Derailleur hanger

      Mondraker M073

    • display

      Display

      Mahle-Ebikemotion

      motor

      Motor

      Mahle-Ebikemotion X-35

    • battery

      Battery

      Mahle-Ebikemotion Internal 250Wh
